GNSS + NavIC with Compass HCR-523
Elevate your drone operations with the HCR-523, a state-of-the-art
GNSS module that combines GNSS and NavIC capabilities with an
integrated compass. Designed and manufactured in India by HC
Robotics Pvt., Ltd., this robust module sets a new standard for
satellite tracking and navigation.
Highlights:
- Increase your Indigenous Content (IC)
- Local sales, support, and repairs
- Low cost yet with global standards
- Built on 16+ years of experience in flight controller technology
- 20+ years of experience in electronics and signal processing
- Rigorous testing: Extensive pre-delivery validation
Features:
- Advanced Dual-Band GNSS Technology
- High Satellite Tracking Capacity
- High-end magnetometer for navigation accuracy
- Rugged and ready-to-go design for extreme durability
- Optimized signal path for maximizing signal-to-noise ratio
-
Precise triggering of cameras using
the timing pulse for synchronized operations -
Rapid satellite fix with battery-backed Almanac
ensuring faster satellite acquisition times - Powerful microcontroller for adaptive real-time operations
-
Ardupilot AP-Periph Firmware Ensures seamless
operation, bug fixes, and compatibility with updates
Highlights:
- Increase your Indigenous Content (IC)
- Local sales, support, and repairs
- Low cost yet with global standards
- Built on 16+ years of experience in flight controller technology
- 20+ years of experience in electronics and signal processing
- Rigorous testing: Extensive pre-delivery validation
Features:
- Advanced Dual-Band GNSS Technology
- High Satellite Tracking Capacity
- High-end magnetometer for navigation accuracy
- Rugged and ready-to-go design for extreme durability
- Optimized signal path for maximizing signal-to-noise ratio
- Precise triggering of cameras using the timing pulse for synchronized operations
- Rapid satellite fix with battery-backed Almanac ensuring faster satellite acquisition times
- Powerful microcontroller for adaptive real-time operations
- Ardupilot AP-Periph Firmware Ensures seamless operation, bug fixes, and compatibility with updates
Specifications:
- U-blox 10th Generation dual-band GNSS Module (NEO-F10N) with support for L1 and L5 signals
- Position accuracy up to 1m CEP
- Navigation Update Rate up to 10Hz
- CAN, USB (GPS only), PPS IO Connectors
- DroneCAN up to 8Mbit/s on FDCAN-enabled devices
Experience the future of precision navigation with the HCR-523 GNSS NavIC with Compass
- Proprietary dual-band multipath mitigation ensures meter-level accuracy, even in challenging urban environments
- Tracks up to 20 satellites, including NavIC (IRNSS) constellations for superior positioning accuracy
- Features the industry-leading PNI RM-3100 geomagnetic sensor for high gain, rapid sampling rates, and zero hysteresis
- Exposes USB connection and precise timing pulse (PPS)
- Special attention to the routing from antenna to chip for impedance matching
- Rough-terrain durability with integrated dust and water resistance
- Undergoes extensive post-production testing to ensure reliability right out of the box
- Equipped with the STM32G4 microcontroller for adaptive real-time operations and high-speed embedded memories
Specifications:
| Model | HCR-523 GNSS NavIC |
|---|---|
| Receiver Type | U-blox 10th Generation dual-band GNSS Module (NEO-F10N) |
| Satellite Constellations | GNSS / QZSS L1C/A (1575.42 MHz), L5 (1176.450 MHz) Galileo E1-B/C (1575.42 MHz), E5a (1176.450 MHz) BeiDou B1C (1575.42 MHz), B2a (1176.450 MHz) NavIC SPS-L5 (1176.450 MHz) |
| Positioning Accuracy | 1m CEP |
| Processor | STM32G4 Microcontroller |
| Geomagnetic Sensor | PNI RM3100 |
| Navigation Update Rate | 10hz max |
| IO Connectors | CAN, USB (GPS Only), PPS |
| Mating Connector | JST-GHR-06V-S JST-GHR-04V-S |
| Communication Protocol for Drone | Drone CAN up to 8Mbit/s on FDCAN enabled devices |
| Supply Voltage | 4.75vDC to 5.5vDC |
| Operating Current | 65mA |
| Operating Temperature | -40℃ to +85℃ |
| Dimensions | 69.6×69.6×24.8 mm |
| Weight | 65g |
